The CMM Jig is a precision-machined stainless steel fixture designed to support accurate and repeatable measurement during Coordinate Measuring Machine (CMM) inspection. Featuring flat reference surfaces and a rigid structure, this jig ensures stable part positioning and reliable dimensional verification for quality control processes.

Features:

• Precision Flat Reference Surfaces: Machined to maintain accurate and repeatable positioning during CMM inspection.
• Rigid Structural Design: Maintains dimensional stability under inspection conditions to ensure consistent results.
• Clean, Burr-Free Edges: Ensures safe handling and compatibility with sensitive measurement equipment.
• Simple Functional Layout: Easy integration into existing CMM setups and inspection workflows.
• High Dimensional Accuracy: Suitable for tight tolerance and precision measurement applications.

Materials:

• Stainless Steel: Offers excellent dimensional stability, corrosion resistance, and durability for metrology and inspection use.

Dimensions:

• Length: Customizable
• Width: Customizable
• Thickness: Customizable

Applications:

Suitable for CMM inspection rooms, quality control departments, precision engineering environments, and dimensional verification processes.

Customization:

Customization options include overall size, slot or cut-out design, mounting holes, tolerance requirements, surface finishing, and material thickness according to inspection needs.
